Tubular Modules

MEMOS tubular ultrafiltration membranes have superior performance and are widely used in various wastewater treatment processes,food and pharmaceutical.


Innovative replaceable membrane module design
Procuct Introduction

          MEMOS Tubular membrane products

  • Membrane materials: polysulfone (PS), polyethersulfone (PES), polyvinylidene fluoride (PVDF)

  • Uses high-performance polymers, with permanent hydrophilicity

  • Cut-off molecular weight from 5k to 250kDa

  • Anti-pollution, stable operating flux

  • Membrane hole diameter available in 6 mm, 8 mm, 10 mm, 12 mm and 24 mm

  • Difficult to block, easy to clean

  • High chemical stability, thermal stability and mechanical stability

  • Suitable for high-concentration and high-viscosity media


Tubular Membrane Product Specification Table

ParameterUnitVFU-030VFU-100VFU-250Remarks
MWCODa30,000100,000250,000
Water fluxLMH 100KPa>60>350>50025℃  100KPa

Diameter

inner side

mm4,6,8,10,12,25
TMPKPs

-50 - 1000 (6mm)

-40 - 800   (8mm)

-30 - 800  (10mm)

-20 - 600  (12mm)


Temperature range

5-70

pH=7  100KPa


pH range
2-11
25℃
Chlorine resistantppm.h250,000





Applications
Technical resource
UNISOL firmly believes that quality is the soul of products
Strictly observe every standard, every process of production, every detail of service
Create maximum value for customers
UNISOL provides professional and thoughtful research and development consulting services for filter membrane components, warmly welcome your consultation
